Opis
Roland Desktop Eco Solvent printer-cutter
Roland VersaStudio BN-20 je desktop – produkcijski Ink-Jet printer iz role maximalne širine 18.9´ili 480mm. Najnovija tehnologija nanošenja boje na materijal sa potpuno redizajniranim print glavama, te u kombinacij sa Eco-Sol Max bojama daje savršen otisak na razne vrste medija. Nova generacija Roland VersaStudio BN-20 ima mogućnost printanja potpuno novim inovacijskim sistemom printanja White, Metallic silver boje, što definitnovo proširuje mogućnosti za ubacivanjem novih proizvoda u Vaš asortiman. Već poznata opcija konturnog rezanja sad već unaprijeđena inovacija. Ova opcija omogućuje konturno rezanje vaše grafike tik nakon tiska bez premotavanja i ponovnog namještanja otprintanih grafika na početnu poziciju za rezanje.
Savršene boje – Roland VersaStudio BN-20
Novi sistem obojenja sa glavom Piezoelectric Ink jet sistemom pružiti će vam potpunu pouzdanost i izvrsnu kvalitetu. Metallic Srebrna EcoSol Max silver ink boja može se printati kao SPOT boja ili u kombinaciji sa CMYK-om daje novih 500 upadljivih metaliziranih i perlastih tonova, a sami printer se može konfigurirati da printa u kombinacijama samo CMYK ili CMYK + White ili CMYK +Silver Metallic CMYK. Roland VersaStudio BN-20 punjenje je 220ml te opcija bijele i srebrne od 220ml taođer. Roland VersaStudio BN-20 namjenjena je za tisak na proizvode poput etiketa i naljepnica, dekorativnih grafika, printanih folija za izloge i naljepnice za izloge, t-shirt i tekstilnog ukrašavanja, te mnogo drugih Rolnad Versa BN Products proizvoda. Zasigurno najbolja opcija desktop Ink-Jet printera na tržištu vrhunske kvalietet izrade. Inovacija tiska iz role na različite proizvode u suvremenoj svakodnevnici. Sve specikikacije mogućnosti i novitete pogledajte na Roland DGA VersaStudio BN-20.
NEW – ROLAND Versa BN-20A
U 2022. Roland je u ponudu uvrstio opciju VersaStudio BN 20A printera. Razlika je u sistemu boja gdje se kod modela BN 20A NE može konfigurirati bijela ili metallic. Printer se isporučuje isključivo sa CMYK sistemom od četri boje. Izbacivanjem tog sistema bijela i metallic Roland je smanjio troškove izrade dodatne komponente, a time i snizio cijenu printera. Za sve one kojima nije ključna bijela ili srebrna boja u ponudi ovo je vrlo povoljno riješenje za tisak na razne medije. Ovaj printer koristi novu generaciju Eco Sol Max2 boje. Boja nove generacije daje oštrije gradijente i punije, te izraženije fotografske detalje. Crna boja donosi još glatkije gradacije sivih tonova, prirodnije nijanse kože i najoštrije fotografske slike. Kvalitetan i konstantan ispis pri većim brzinama. Gotovo bez mirisa, bez prisutnosti nikla. Brzo se suši i otporan na ogrebotine za brzu, jednostavnu završnu obradu i širok raspon boja za tamnocrvenu, plavu i zelenu. Odlično prianja na niz nepresvučenih pristupačnih medija. Trajnost do tri godine na otvorenom bez laminiranja.
Koje sve folije i materijale možete printati na Roland VersaStudio BN20 printeru:
- Termo folije za apliciranje na razne tekstilne proizvode (Hot mark, Glitter, Solvent Flock, Glow in the dark, SubliStop te razne druge varijante termo folija) na linku možete pogledati koje su tekstilne print/cut folije kliknite ovdje
- Viny naljepnice za printanje iz role koje se koriste za apliciranje na razne podloge (vozila, staklo, kutije, zidna tapeta, boce za vino te široka paleta raznih proizvoda i materijala na koje se mogu zaljepiti) dolaze u Glossy i Matt varijanti.
- Mesh banner – rupičasta folija za oslikavanje izloga.
- Poster papir 150 grama za printanje plakata i postera.
- Canvas materijal za izradu slika.
Roland VersaStudio BN-20 printer/cutter konfiguracija CMYK + White and Metallic
- Eco-Sol MAX | CMYK + White and Metallic Silver Ink
- 220 ml punjenje za Metallic i Silver
- Eco Sol Max 2 220 ml ink CMYK za BN20 (startno punjenje)
- Eco Sol Max 2 440 ml ink CMYK za BN 20 (standardno punjenje)
Roland VersaStudio BN-20A printer/cutter konfiguracija
- Eco Sol Max 3 220 ml ink CMYK za BN20A (startno punjenje)
- Eco Sol Max 3 500 ml ink CMYK za BN 20A (standardno punjenje)
Versa BN 20 Specifikacije
| Model | VersaStudio BN-20 | |
|---|---|---|
| Printing method / Cutting method | Piezoelectric inkjet / Grit roller feed | |
| Acceptable media | Width | 5.9 to 20.3 in. (150 to 515 mm) |
| Thickness | Printing: Maximum 39 mil (1.0 mm) with liner | |
| Cutting: Maximum 16 mil (.4 mm) with liner | ||
| Roll Weight | Maximum 13.2 lbs (6 kg) | |
| Roll Outer Diamater | Maximum 5.9 in (150 mm) | |
| Core Diamater | 2 in (50.8 mm)or 3 in (76.2 mm) cores | |
| Printing/cutting width1 | Maximum 18.9 in (480 mm) | |
Ink cartridges |
Type | |
| Ink Cartridges | Type & Capacity | Roland ECO-SOL MAX or FPG Aqueous, 220 ml only |
| Colors | 5 Color – CMYK+Mt (Cyan, Magenta, Yellow, Black and Metallic Silver) or CMYK+Wh (Cyan, Magenta, Yellow, Black, and White) | |
| 4 Color – CMMYK (Cyan, Magenta, Yellow, Black) | ||
| Printing resolution | Max 1440 dpi | |
| Cutting Blade | Type | Roland CAMM-1 series cutter blade |
| Blade Offset | Fixed at 0.250 mm | |
| Cutting speed | 0.4 (10 mm/s) to 5.9 in/s (150 mm/s) | |
| Blade force | 30 to 300gf | |
Software resolution (when cutting) |
0.000984 in/step (0.025 mm/step) | |
| Distance accuracy (when printing)2,3 | Error of less than ± 0.3 % of distance traveled, or ± 0.3mm (0.012 in), whichever is greater. | |
| Distance accuracy (when cutting)2,4 | Error of less than ± 0.4 % of distance traveled, or ± 0.3mm (0.012 in), whichever is greater. | |
| Repetition accuracy (When cutting)2,5 | ±0.004 in (± 0.1mm) or less | |
| Alignment accuracy for printing and cutting2,6 | ±0.020 in (± 0.5mm) or less | |
| Alignment accuracy for printing and cutting when reloading media2,7 | Error of less than ± 0.5% of distance traveled, or ± 0.012 in (3mm), whichever is greater | |
| Print Heater Temperature8 | Fixed at 95o F (35oC) | |
| Connectivity | USB 2.0 | |
| Power-saving function | Automatic sleep feature / AC 100 to 240V ± 10%, 1.5 A, 50/60 Hz | |
| Power Consumption | During Operation | Approx. 90 W |
| Sleep Mode | Approx. 5.5 W | |
| Acoustic Noise Level | During Operation | 62 dB (A) or less |
| During Standby | 42 dB (A) or less | |
| Dimensions/Weight | 39.2″ W x 23″ D x 11.5″ H (995 W x 585 D x 291 H mm), 79.4 lbs (35 kg) | |
| Operating Conditions | Power on | Temperature: 68o – 90o F (20 to 32o C), humidity: 35 – 80% RH (non condensing) |
| Power off | Temperature: 41o – 104o F (5 to 40o C), humidity: 20 – 80% RH (non condensing) | |
| Included Items | Power cord, USB cable, blade, blade holder, Rolandsoftware Package9, Software RIP (VersaWorks), User’s Manual, etc | |
Versa BN 20 Specification |
||
| *1 The length of printing or cutting is subject to the limitations of the program. | ||
| *2 Using Roland specified media, loaded correctly, temperature: 25°C (77°F), humidity: 50 %RH, all pinch rollers are used, 25 mm or more for both right and left margins and 35 mm or more front margin, excluding expansion or contraction of the emdia, and all correction and adjustment functions of this machine have been made properly. | ||
| *3 Using Roland specified media, print travel of 1m. | ||
| *4 Using Roland specified media, cut travel of 1m. | ||
| *5 Range for assured repetition accuracy: Length 1,000 mm. | ||
| *6 Provided that media length is under 1,000 mm. Excluding possible shift caused by expansion/contraction of the media and/or by reloading the media. | ||
| *7 Using Roland specified media, data size: 1,000 mm in the media-feed direction, 480 mm in the carriage-movement direction. No lamination. Automatic detection of crop marks at 4 points when media is reloaded. Excludes the effects of skewed movement and of expansion and contraction of the media. | ||
| *8 Warm-up is required after power up. This may require 5 to 20 minutes, depending on the operating environment. The preset temperature may fail to be reached 35°C (95°F) depending on the ambient temperature and media width. | ||
| *9 Roland Software Package includes: Windows driver, OnSupport software, utility software and R-Works design software | ||
| Roland VersaWorks 6 System Requirements |
| Operating system | Windows® 10 (32/64-bit) | |
| Windows® 8.1 (32/64-bit) | ||
| Windows® 7 Professional / Ultimate (32/64-bit) | ||
| CPU | Intel® Core™2 Duo, 2.0 GHz or faster recommended | |
| RAM | 2 GB or more recommended | |
| Video card and monitor | A resolution of 1,280 x 1,024 or more recommended | |
| Free hard-disk space | 40 GB or more recommended | |
| Hard-disk file system | NTFS format | |
| Optical drive | DVD-ROM drive | |
| Other requirements | Ethernet or USB port Internet connection and web browser to use Roland@NET |
|
Important note*
Please note: Considering that you will be using software such as Illustrator, we recommend that you use as high performance computer as possible to reduce RIP processing time. We also recommend using a hard disk that has large enough capacity, as print files are often tens of GB in size (or larger) when data is high resolution.
* Roland VersaWorks 6 is a 32-bit application, which runs on 64-bit Windows® with WoW64 (Windows 32-bit on Windows 64-bit).
